Provide TS QoS statistics including stream down time, and percentage of time critical errors occurred on streams.ĭisplays visual error alarms on Multiviewer panels, and audio alarms by client applications

Generates test reports, including reports of periodical error summaries occurrences of specific errors TS quality scores over time. Provides database search functions based on time, error code, stream name and keyword. Records all transport stream errors in the database Transport Stream Error Records and Reports Reports errors when actual bitrate is out-of-bound. Uses TS templates to monitor expected PIDs and their bitrate range. Monitoring Setting and Configurable ThresholdĪllow users to change thresholds, including metadata tables interval, PCR, and audio and video buffer threshold Summarizes and quantifies transport stream errors using a single quality number Real-time display of the latest errors occurred in streamsĭetect the loss of audio and video components Monitors TR 101 290 priority level 1, 2, 3 errors Performs video and audio elementary stream buffer analysis and monitors buffer overflow and underflow conditionsĭecodes PTS values, calculates and displays frame PTS intervals Performs PCR analysis on each program, calculates PCR precision, interval, and frequency offset Records and reports table decoding errors and syntax errors, including CRC errors Monitors the appearance of each metadata table or missing of required meta tables, calculates its repetition time interval, and tests standard compliance Graphical display of real-time PID bitrate charts.ĭecodes MPEG PSI metadata tables and displays transport stream structureĭecodes all DVB SI metadata tables, and displays EPG informationĭecodes all ATSC PSIP metadata tables, and displays EPG informationĭecodes and displays SCTE-35 ad splicing message tablesĭisplays metadata table content in a hierarchical tree structure

Monitors PID bitrate and calculate min, max and average. Transport Stream Data and Structure Analysis Support TS input over ASI input interface Monitors up to 250-300 SPTS streams for real-time analysis by a single computer server or 250 services in MPTS Supports IGMPv2 and IGMPv3 for source-specific multicast controlĪutomatically discovers all IP transport streams in a network Support TS over HTTP, RTSP, RTMP, MMS Streaming Support UDP unicast and multicast streams Transport Stream Analysis and Error Monitoring An optional web server can be used to connect to multiple monitoring servers in different locations to access test results and control these servers remotely.

#Connect 2x1 multiviewer to computer software#

Mividi supplies fully-built systems or software which can be installed on customers’ own hardware.

#Connect 2x1 multiviewer to computer Pc#

The monitoring system is built on standard PC or servers using Windows 7, 10 or Windows Server 2008, 2012, 2016, 2019. Users can select alarms to be triggered by certain errors. Any transport stream errors are logged in a database for review and reporting. More video programs can be monitored using program rotation and penalty box features. It can simultaneously display up to 60 SD video or 30 HD video programs, analyze and record the streams. The system provides a real time multiviewer display of video or audio services coming from different input interfaces including IP and DVB ASI. It supports MPEG-2, MPEG-4, AVC (H.264), and HEVC (H.265) video compression formats, as well as commonly used audio formats. The Mividi IMS120 can be used for monitoring DVB and ATSC broadcast streams, as well as online media using various online streaming protocols. It will pay for itself in manpower savings over a short period of time. It is a single Windows based system that can complete tasks previously done by several different pieces of equipment. The IMS120 was developed to automate monitoring and error diagnosis at digital head-ends for broadcasters, MSOs, Telcos and online streaming video providers. The Mividi IMS120 is a broadcast transport stream monitoring system for viewing video and audio services, analyzing transport streams, logging errors, generating alarms, and recording stream.

#Connect 2x1 multiviewer to computer tv#

Broadcast TV Multiviewer Monitoring - IMS120.
